Physical Characteristic:
* MATERIAL:
  Housing: Thermal plastic(PA6T+30%G.F.); UL94V-0
  Contact: Brass,

* FINISH:
  Contact: Gold Plating on contact area;
         50u" min. Nickel underplating over all.

* SPECIFICATION:
  Voltage/Current Rating:250V/0.5Amp/Pin Min. ;
  Insulation Resistance: 1000 MΩ Min. ;
  Contact Resistance: 20 mΩ Max. ;
  Dielectric Withstand Voltage: 500V AC R.M.S ;
  Operating Temperature: -45°C ~ +85°C.

* MECHANICAL PERFORMANCE:
   Insertion Force: 3.5kgf max.
   Remove Force: 1.5kgf min.
   Durability: 25 cycles
