Pin Header, 2.0mm Pitch, Dual-Row, Vertical SMD
Product No
F4Fxxxxx-A08xxxH
Product Description
2.0mm Pitch, Dual-Row, Vertical SMD, W/O Post or W/Post
Physical Characteristic:
1. Materials:
1.1 Housing: Nylon 6T, UL94 V-0; Color: Black
1.2 Contact: Brass
2. Plating:
2.1 Contact: Gold flash plated over 50u" Min. Nickel
3. Electrical characteristics:
3.1 Current rating: 2.0 AMP.
3.2 Dielectric Withstanding Voltage: AC 500V.
3.3 Insulation resistance: 3000 MΩ Min.
3.4 Operating Temperature: -40ºC ~ +105ºC
1. Materials:
1.1 Housing: Nylon 6T, UL94 V-0; Color: Black
1.2 Contact: Brass
2. Plating:
2.1 Contact: Gold flash plated over 50u" Min. Nickel
3. Electrical characteristics:
3.1 Current rating: 2.0 AMP.
3.2 Dielectric Withstanding Voltage: AC 500V.
3.3 Insulation resistance: 3000 MΩ Min.
3.4 Operating Temperature: -40ºC ~ +105ºC
